DIELECTRIC介質
|
Polyester film 聚脂薄膜
|
|
ELECTRODES 電極
|
Vacuun evaporated metal真空蒸鍍金屬
|
|
COATING包封
|
Out wrapped with Mylar tape and ends sealed with epoxy resin
瑪拉膠帶包封，環氧樹脂封裝
|
|
LEADS導線
|
Axial leads of tinned wire軸向鍍錫導線
|
|
REFERENCE STANDARD 引用標準
|
IEC 384-2 grade 1；SJ/T 10873-1996
|
|
CLIMATIC CATALOGUE 氣候類別
|
40/85/21 (From 85℃ up to 105℃ with derating voltage 1.25%/℃) （85℃至105℃間按1.25%/℃遞減電壓）
|
|
APACITANCE VERSUS RATED
VOLTAGE(U R)
靜電容量與額定誤差
|
M=±20% K=±10% J=±5%
|
|
DISSIPATION FACTOR（TANGENT OF LOSS）
散逸因素（損耗角正切
|
C≤1.0μF DF≤0.8%
C＞1.0μF DF≤1.0% (at 20℃,1KHz)
|
|
VOLTAGE PROOF耐電壓
|
1.6*U R Unit:VDC (5s at 20℃)
|
|
INSULATION RESISTANCE 絕緣電阻
|
C≤0.33μF, IR≥15000MΩ;
C＞0.33μF, IR*C≥3000S (1minute at 20℃ and RH≤65%)
|
|
ENDURANCE 耐久性
|
1000 hours with 125% of rated voltage at 85℃,After the Test:
85℃試驗溫度下，125%之額定電壓1000小時,
△C/C≤8%；△DF≤0.30%（C＞1μF）；
△DF≤0.50%（C≤1μF）;
IR≥0.5% of the specified value （標稱值）. （20℃ 1KHz）
|
